Specify the complete pigtail, beginning with the series identity
Use 1 mm² DC power pigtail as the series identity in your inquiry, then identify the connector configuration your project requires. The listed range includes DC5525 and DC5521 male and female choices. State one selected configuration per requested item and give that item a purchasing reference. Keep alternatives separately identified if your engineering team has not yet made a choice.
Ask for a proposed cable drawing that covers the connector, cable and wire end together. Include the mating-part reference and the intended connection method at the opposite end. This lets your team review the proposed item as an assembly rather than making a purchasing decision from the cable series name alone.
If your inquiry begins with an existing cable, identify which details you want retained and which need review. Use photographs to explain the reference, with labels for the connector and wire-end features of interest. Provide dimensions or drawings where available, and keep unknown details marked as questions for the proposal.
Keep the 1 mm² identity distinct from application requirements
The product is identified as a 1 mm² DC wire series. Use that identity accurately in the requested item description, while providing the operating requirements your engineering team needs considered for the complete cable. Ask for the proposed construction to be described against those inputs and identify any supporting documents required for your purchasing decision.
For a project reviewing a cable change, state the reason for the review as a requirement or question. Your brief might ask for a proposed pigtail against an updated assembly specification, with the connector and wire-end preparation shown in the linked drawing. Keep the required performance criteria in that specification rather than assigning them from the series name.
Ask your engineering team to review the connector, cable construction and termination requirements together. If the project requires a particular dimension, material detail or document, list it explicitly. Keep the final proposal tied to the selected configuration so that a series identity does not replace the complete item description on the order.
Connector, length and sheath choices in the series
The series lists DC5525 and DC5521 male and female connectors. Its cable length choices are 20, 50, 100 and 200 cm, with customized lengths also listed. Black or customized color and PVC or rubber outer sheath options are included. Select the choices you want considered and ask for the proposed combination to be confirmed.
For the connector, identify the mating-part reference and request the dimensions needed for your review. For the sheath, describe the requirements your team wants considered alongside the listed material choices. For color, state whether the request is black or a custom reference and explain how your team intends to review that reference if needed.
If several configurations are being considered, put the alternatives in a short table of your own. Include the connector identity, gender, requested length and sheath choice for each item. Name the preferred configuration and identify the decision still required for the others. This gives the quotation discussion a clear set of requested choices.
| Item | Series information |
|---|---|
| Series identity | 1 mm² DC wire |
| Connector choices | DC5525 / DC5521 male or female |
| Lengths | 20 / 50 / 100 / 200 cm or customized |
| Color | Black or customized |
| Outer sheath | PVC or rubber |
Describe the termination your assembly process needs
Give the wire end a detailed requirement in the drawing. Explain the intended connection method and ask which preparation can be supplied for the proposed cable. State the dimensions your assembly team needs, with a reference point for each one. If another component is involved in the termination, include its drawing or specification as a mating reference.
Prepare the intended contact-to-wire relationship, including polarity and any identification your team uses. State the viewing direction on connector diagrams. Keep these connection requirements separate from the selected outer sheath color. Ask for the proposal to be reviewed against the connection map together with the wire-end preparation details.
Where your process uses a particular acceptance method for the termination, describe the requirement and discuss the proposed arrangement. Identify any documents you need before making the purchasing decision. Keep open preparation questions visible in the inquiry rather than assuming they have been settled by the word pigtail.
Establish the length from the actual route
Show the connector position and the intended wire-end connection on an assembly sketch. Draw the route between them and identify any assembly position that your team needs considered. Ask the layout owner to establish the required dimension from that route. If the route is provisional, identify the decision needed before the length can be finalized.
Mark the measurement endpoints on the cable drawing and state your required tolerance. If a reference cable is supplied as background, explain how its length was measured. Use the same convention for the proposed item or clearly describe the requested change. Keep the final dimension attached to the item reference used in the quotation.
Custom lengths are listed alongside the published options. Submit the dimension your assembly requires and ask for it to be confirmed for the chosen connector and sheath configuration. For several routes, identify the corresponding cable items separately and state which other requirements should remain common across them.
Prepare a quotation brief for a construction review
A useful request can start with the 1 mm² DC series identity and the selected connector choice, followed by your assembly drawing and operating requirements. State the wire-end preparation and selected length, then add sheath and color preferences. This sequence keeps the construction discussion connected to the proposed item your team actually wants to purchase.
For example, a buyer might write, 'Please propose the selected pigtail against our linked cable drawing, including the connector and wire-end requirements. Identify any specification detail that needs clarification before the item is finalized.' Treat that as a request format and replace it with your own item reference, documents, requested quantity and open questions.
Share the specification link through contact or send it by email. The customization page can help organize the length and appearance questions you want discussed. Include your requested schedule and any sample-stage requirement as items for confirmation, together with the technical description.
Review the sample against defined acceptance questions
If a sample proposal is requested, tell us what the review is intended to establish. Your team may need to examine the mating interface, the route or the intended termination process. Identify the applicable drawing revisions and the requirements each review will address. Discuss any checks and supporting records needed before the proposed item is approved.
Record the decision for each requirement separately. An accepted length can remain accepted while another dimension is revised, provided your team records that distinction clearly. Ask for an updated proposal when changes are requested and compare the new description with the drawing your buyer will use for the purchase.
For receiving review, consider maintaining the agreed item description with the purchase documents. Specify the identification and review criteria your team needs to distinguish the supplied configuration from alternatives considered earlier. Keep the connector choice, length and sheath selection visible in the description rather than relying only on the series name.
Compare proposals against the same construction brief
When reviewing more than one proposal, use your selected item specification as the common reference. Record the connector choice, length, sheath and wire-end preparation described in each proposal, and identify any difference from your request. Ask for clarification where a description is incomplete rather than treating missing detail as agreement. Keep the proposed commercial terms beside the corresponding configuration so your buyer can compare defined items. If your team selects a changed configuration, update the specification before approving the purchase instead of leaving the decision only in the quotation discussion.
Keep future changes tied to the selected configuration
If your equipment specification changes after the first inquiry, identify the affected cable requirement and share the revised drawing. State whether the connector choice, route or termination remains the same. Ask for the new proposal to use the current item revision so the purchasing discussion does not combine old and new requirements.
The DC product catalog can help your team revisit the available product identities if the required connection arrangement changes. When the configuration is selected, request confirmation of the proposed item, quantity and commercial terms together. Retain the agreed specification for a repeat inquiry and describe any later changes explicitly.
Before releasing an order, compare the quoted description with the current drawing and your list of required documents. Confirm the chosen connector, selected length, sheath, color and wire-end requirements. Keep open questions separate from approved details until your team has the information it needs to complete the purchasing decision.
Frequently asked questions
Which connector choices are listed for this pigtail series?
The 1 mm² DC series lists DC5525 and DC5521 male and female connector choices. Select the configuration required by your project and provide its mating-part reference for the proposed drawing review.
What cable lengths are listed?
The series lists 20, 50, 100 and 200 cm, with customized lengths available. State your requested dimension, measurement endpoints and tolerance, and ask for confirmation of the selected combination.
Does the 1 mm² identity define my complete application specification?
Provide your complete operating and connection requirements in the inquiry. Ask for the proposed cable construction to be reviewed against those inputs, together with the connector and wire-end preparation your project requires.
Can I discuss sheath and color choices?
The series lists PVC or rubber outer sheath options and black or customized color. Identify the selected choices and any project requirements you want considered, then review the proposed combination before ordering.
